2026 SANDVIK RANGER DX810I
additional information
- Ranger™ DX810i is designed with a revolving superstructure that provides 290° reach. Achieve 55 square meters of drilling coverage and increase productivity by reducing the time spent repositioning your rig.
- Ranger™ DX810i has a selection of rock drills from the powerful RD900 rock drill family (21 kW - 25 kW), making the drill rig suitable for several applications, like road cutting, pipeline drilling, foundation drilling and production drilling in medium size quarries.
- Operators experience a noise level of 73.5 dB in the comfortable iCab cabin.
- Enhance drilling productivity with My Sandvik Productivity or My Sandvik Onsite fleet performance monitoring and optimizing systems. View fleet performance, equipment health and utilization in one place, ensuring optimal efficiency and performance.
- Harness intelligent features and advanced options, including innovative iTorque control system, precise hole-to-hole navigation, one-hole automation and TIM3D technology.
- Boost drilling efficiency with curved thread Sandvik CT55 rock tools and achieve up to 20% higher penetration.
- Specifications and data shown are subject to change with or without prior notice.
- Year: 2026
- Manufacturer: SANDVIK
- Model: RANGER DX810I
- Condition: New
- Specifications Hole Diameter: 64.0 - 127.0 mm (2.5 - 5.0 in.)
- Specifications Rock Drill: 21 - 25 kW
- Specifications Flushing Air Capacity: 8.5 m³/min up to 10 bar
- Specifications Drill Rod/tube Diameter: 38, 45 or 51 mm (1.5, 1.75 or 2 in.)
- Specifications Hydraulic Rock Drill: RD925M (25 kW) / RD921S (21 kW)
- Specifications Engine: Volvo TAD881VE (EU Stage V, T4F), Volvo TAD851VE (T3)
- Specifications Cabin: iCab
- Specifications Transport Length: 12.4 m (40.7 ft)
- Specifications Transport Width: 2.45 m (8.00 ft)
- Specifications Transport Height: 3.3 m (10.8 ft)
- Specifications Weight: 19,600 kg (43,210 lb)
